GS Series
May not be exact product – for reference only.
GSC024C
Lead Time:
5 Days
function
General Purpose Slim Relay
control voltage
24V AC/DC
output
6A 1 Form C
TIMING RANGE
TIMING RANGE 2
MOUNT
35mm Din-Rail
Setting Adjustment
None
Options
None
$14.92
Description of Function
Compact GS Series General Purpose Relays are used for high density applications. The relay and sockets are assembled as one unit and must be used together, providing DIN-rail mounting. The relay and socket installation provides finger protection, indication of power status, and 1 Form C output contact.
Product Overview
Features:
• Compact size (6mm)
• 1 Form C contact
• Secure relay/socket retention with easy ejection
• High Capacity 6 Amp rated
• Finger Safe Protection. LED indication
• 10,000,000 mechanical operations
• RoHS compliant
• UL/cUL, CE approval
• 1 Form C contact
• Secure relay/socket retention with easy ejection
• High Capacity 6 Amp rated
• Finger Safe Protection. LED indication
• 10,000,000 mechanical operations
• RoHS compliant
• UL/cUL, CE approval
Enclosure Style:
Din-Rail
Configuration / Contact Rating:
1 Form C 6A @ 250V AC / 6A @ 30V DC, 1500VA/180 W
Application Information:
• Load (Burden): Maximum 250 mW
• Voltage Tolerance: ±10% nominal coil voltage
• Wire Size: 16-20 AWG, solid or stranded
• Terminal Tightening: Recommended torque, 4.43 in-lb
• Life:
Mechanical: 10,000,000 operations
Electrical: 30,000 operations
• Temperature:-40°C to 70°C (-40°F to 158°F)
• Unit Weight: Approximately 0.07 lb (32 g) relay + socket
• Voltage Tolerance: ±10% nominal coil voltage
• Wire Size: 16-20 AWG, solid or stranded
• Terminal Tightening: Recommended torque, 4.43 in-lb
• Life:
Mechanical: 10,000,000 operations
Electrical: 30,000 operations
• Temperature:-40°C to 70°C (-40°F to 158°F)
• Unit Weight: Approximately 0.07 lb (32 g) relay + socket
Approvals:
