FREQUENTLY ASKED QUESTIONS
Have Technical Questions? Here Are Some Quick Answers.
Our FAQ page is the place where visitors share technical questions about how to apply our products in both simple and complex applications. Got a question? Need troubleshooting help? Start here to find a quick solution.
Reset Timers
Macromatic RT series Reset Timers are electronic and microprocessor based. This design approach offers highly reliable, repeatable and accurate timing cycles. The RT series is available with or without memory. For applications that require memory, the standard RT Series retains timing cycle status when power is lost. When power is restored the timer continues timing without resetting the timing cycle. For applications that do not require memory, Macromatic offers the product without memory as well. The non-memory version resets the timing cycle to zero when power is removed. When power is reapplied, the timing cycle always starts at the beginning.
Macromatic eCommerce
At any time, you can click on “LOG IN” in the upper right corner of the website. On the LOG IN screen, you can register as a Returning Customer or create a New Customer account. After clicking the blue “LOG IN” button, returning customers will see the “My Account Dashboard” where you can manage your information, including any orders you have placed. After clicking the blue “ADD NEW ACCOUNT” button, new customers will receive an email message with further instructions.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
At any time, you can click on “LOG IN” in the upper right corner of the website. On the LOG IN screen, you can register as a Returning Customer or create a New Customer account. After clicking the blue “LOG IN” button, returning customers will see the “My Account Dashboard” where you can manage your information, including any orders you have placed. After clicking the blue “ADD NEW ACCOUNT” button, new customers will receive an email message with further instructions.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
All prices shown on the website are List Prices (USD).
All new online customers who sign up for an account receive a one-time 10% discount on their first order (applied during checkout). Fill out the “New Customer” form prior to placing your order.
Authorized Macromatic Distributors must fill out the Registration Form for account approval and special pricing. Click on the text link on the upper left corner of the Checkout screen. Once your status is verified, you will receive a second email confirming that status. Any orders placed before verification will receive the List Price shown on the website.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
Accessories
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
When used with the appropriate Macromatic socket, the relay-socket combination is UL Listed. Macromatic products can be used with compatible 3rd party sockets as well. When used with 3rd party socket, the product is a UL recognized component.
Voltage Monitor Relays
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
Voltage band relays monitor for over and under voltage conditions simultaneously energizing the output relay only when the voltage is within the proper “band” or range of voltage set using the adjustment dials on the relay. Contrast this to voltage “over/under” relays that simply energize the relay output when voltage is above the dial setting threshold.
Voltage Monitor Relays monitor either AC single phase (50-60Hz) or DC voltages to protect equipment for undervoltage and overvoltage fault conditions. The relays can be used as either overvoltage or undervoltage relays, depending on the output contact used. Overvoltage models provide protection to equipment that cannot handle excess voltages. Undervoltage relays provide protection to equipment that is required to operate above a certain minimum voltage. Voltage Band Relays provide protection to equipment that is required to operate within an upper and lower voltage limit. As long as the operating voltage remains within an OVER & UNDER voltage range, the internal relay stays energized. If the operating voltage falls outside this range, the relay will drop-out.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
Macromatic maintains an extensive cross reference database. Follow the link here.
Time Delay Relays
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
If you need to set the ON and OFF time independently on a cycle timer then you need to select a product with either Repeat Cycle ON or repeat cycle OFF function. Although the operation is similar, Flasher ON and Flasher OFF function do not allow for independent setting of the ON and OFF times.
This is an OFF Delay function. This function is available in several of our time delay relay product lines. Select the time delay relay series that works best for your application.
Product specifications for all Macromatic time delay relays state a minimum of 50 ms in length for the application of a trigger.
Macromatic maintains an extensive cross reference database. Follow the link here.
We provide a detailed description and graphical representation of all our time delay relay function to help with selection, see link.
Macromatic time delay relays rated for 240VAC have an operating range of 204-264VAC for control voltage and are suited for 208/220/230/240/250V applications.
The function you are describe is the Retriggerable One Shot, setting E. The timing will start when there is a connection between A1 and S. This can be accomplished with a momentary or sustained switch placed between the two terminals.
Three-Phase Monitor Relays
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
Macromatic maintains an extensive cross reference database. Follow the link here.
All Macromatic three phase monitors offer phase loss protection to allow you to protect your equipment form damaging single phase conditions. Select the phase monitor relay that best fits your application needs.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
Yes, the PMP and PMD Series offer a user-adjustable delay of 0.3 – 30 seconds trip delay for Unbalance, Overvoltage, and Undervoltage faults. Remaining Macromatic three phase monitor relays have factory set time delays built in to minimize nuisance trips while offering best in class protection.
A phase reversal condition would cause rotating equipment to run backwards. Most often this condition occurs due to miswiring during service. All Macromatic three phase monitor relays include protection from phase reversal allowing you to prevent running of the equipment under this condition.
Seal Leak & Temperature Relays
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
Some submersible pumps have non-standard seal and temp sensors. Visit this link to help determine which product is best for your pump.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
Macromatic maintains an extensive cross reference database. Follow the link here.
First consult pump documentation as some pumps have specific requirements. If none, dial the sensitivity to its highest level(highest resistance). If the relay gives no alarm you are done. If you receive a seal alarm, adjust the sensitivity back down until the alarm clears. Typical seal leak detection applications use sensitivity settings from 5K to 50K ohms. Lower values are less prone to nuisance alarms but are also less sensitive to the onset of seal leakage.
Percentage Timers
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
A Percentage Timer is a time delay relay commonly used in applications such as irrigation, chemical feeding, electric heating & cooling, motors and lubrication systems. Early Percentage Timer designs were mechanical and used motors and gears to perform the timing function. The mechanical nature of these early designs also means that they are susceptible to variations in voltage and frequency. Macromatic PTA series Percentage Timers are electronic and microprocessor based. This design approach offers highly reliable, repeatable and accurate timing cycles. Changing voltage and frequency does not impact the time range or timing cycle.
Macromatic maintains an extensive cross reference database. Follow the link here.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
Macromatic PTA series Percentage Timers are electronic and microprocessor based. This design approach offers highly reliable, repeatable and accurate timing cycles. The PTA series is available with or without memory. For applications that require memory, the standard PTA series retains timing cycle status when power is lost. When power is restored the timer continues timing without resetting the timing cycle. For applications that do not require memory, Macromatic offers the product without memory as well. The non-memory version resets the timing cycle to zero when power is removed. When power is reapplied, the timing cycle always starts at the beginning.
Liquid Level Control Relays
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
Actual resistivity of ligiid varies and should be calibrated once installed. Standard resistivity values for common liquids can be found here.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
Macromatic maintains an extensive cross reference database. Follow the link here.
Level probes can be made from any conductive material. The head of a bolt through the sidewall or a threaded rod suspended from above are often used as probes with wires attached using ring terminals.
Intrinsically Safe Barrier Relays
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
An Intrinsically Safe Barrier Relay allows reading the status of contacts or sensors in a hazardous location and using this to control equipment or processes outside of the hazardous location safely without introducing risk of explosion.
Macromatic maintains an extensive cross reference database. Follow the link here.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
A barrier is a component that provides protection to a properly designed sensor and control circuit. A barrier relay is a complete solution that provides the protection, sensor circuit, control, and safety certification.
General Purpose Relays
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
Small profile General Purpose relays are economical for use in control panels with limited space. The test buttons on our relays are color coded for easy testing and troubleshooting of control logic systems – orange for AC and blue for DC units. The buttons can be locked in place with a simple 90-degree rotation. Transparent covers allow easy monitoring of operation and the condition of the contacts. Wiring diagrams and terminal identification is printed on the enclosures.
Current Sensing Relays
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
The maximum monitored voltage for our encapsulated CAH, COH, abd CUH Series relays is 250V. Our relays with plug-in enclosures have a maximum voltage level of 500 V.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
Yes, the CAP Series plug-in style current monitors can monitor AC and DC current. Note that these devices must be powered by AC voltage.
Macromatic maintains an extensive cross reference database. Follow the link here.
Alternating Relays
Our wide array of sockets can accept stripped wire, ferrules, ring and fork terminals. Read more details about the size and types of terminal a specific socket can accept.
If you are an Authorized Macromatic Distributor, click on “Registration Form” at the upper left corner on the Checkout page.
You can also LOG IN after selecting products. On the Checkout page you can register as a Returning Customer, create a New Customer account, or use Guest Checkout.
A Macromatic ARP Series Duplex Controller combines the function of an alternating relay, control relay and auxiliary contacts in one unit to provide Sequence On – Simultaneous OFF (S.O.S.O.) functionality. For 120V applications see ARP120A8R and for 24V applications use ARP024A8R.
Macromatic maintains an extensive cross reference database. Follow the link here.
Macromatic relays specify the power consumed by the device as “burden” in units of VA. Look for the burden specification in the catalog page for the specific device you have. The unit of VA(volt-amps) is essentially the same as Watts(power), current draw can be calculated in Amps by taking the VA specification and dividing by the voltage control voltage you are using to power the device.
Our triplex alternating relays can be used to alternate between 3 different loads. They also support running multiple pumps under high demand, provide built in time delays, and switch out of sequence protection.
